Manufacturer: Mingyang
Solar PV & BIPV · Windows, skylights and canopies
Mingyang Semi-Transparent PV Module MY-3CT (0–60% transparency)
CdTe thin-film PV glass of 1200 × 600 × 6.8 mm in four transparency levels, from 115 W at 0% to 46 W at 60% transparency.
Product code: SPC-PV-MY-STT
Use case
A hotel covers its winter garden with semi-transparent PV glass at 40% transparency.
Guests sit in soft daylight with a view of the sky, while the roof generates power for the restaurant’s kitchen and lighting.
How it works
Choose the light
Four standard transparency levels, 0%, 20%, 40% and 60%, set the balance between daylight and power.
Good in low light
According to the manufacturer, the thin-film module performs well in the morning, in the evening and in cloudy or hazy conditions.
Light and thin
6.8 mm and 12 kg per module: 3.2 mm CdTe glass, 0.4 mm EVA and 3.2 mm back glass.
Specifications
| Parameter | Value |
|---|---|
| Manufacturer | Mingyang |
| Technology | Cadmium telluride (CdTe) thin film, glass-glass |
| Models / transparency | MY-3CT0 0% · MY-3CT20 20% · MY-3CT40 40% · MY-3CT60 60% |
| Maximum power (STC) | 115 W / 92 W / 69 W / 46 W (±5%) |
| Vmpp / Voc | 101.8 V / 125.5 V (all models) |
| Impp | 1.13 A / 0.90 A / 0.68 A / 0.45 A |
| Isc | 1.24 A / 0.99 A / 0.74 A / 0.50 A |
| Size, weight, area | 1200 × 600 × 6.8 mm · 12 kg · 0.72 m² |
| Build-up | 3.2 mm CdTe glass + 0.4 mm EVA + 3.2 mm back glass |
| Cable, connector, junction box | 2.5 mm², 650 ± 10 mm · MC4 · IP67 |
| Operating temperature | −40 °C to +85 °C |
| Temperature coefficients | Pmax −0.29 %/°C · Voc −0.28 %/°C · Isc +0.04 %/°C |
| Max. system voltage, fuse rating | DC 1000 V (IEC) · 6 A |
| Application class | A2 |
| Wind and snow load | 6000 Pa (IEC) |
| Packing | 50 modules / pallet (700 kg) |
| Warranty | 10-year product warranty, 25-year performance warranty (more than 85% power after 25 years; 2.0% in year 1, then 0.5% per year) |
| Certificates (manufacturer documents) | VDE marks approval No. 40049441 (EN IEC 61730-1/-2:2018; the product also fulfils IEC 61215:2016), thin-film terrestrial PV modules · ISO 9001, ISO 14001 and ISO 45001 (SGS) for CdTe module manufacture |
Manufacturer: Mingyang. Offered and supported in Poland by Space BMS sp. z o.o. Enquiries: +48 533 909 533 or the contact form on this website.
Mingyang projects are prepared together with the manufacturer’s BIPV engineering team.
All technical data are manufacturer declarations. Specifications may change without notice. Edition 10.2026.
How we work with you
- Site visit and roof or car-park survey.
- Yield estimate and system layout for your building.
- Structural and grid-connection check with your designer.
- Installation by qualified partners and commissioning.
Detailed technical documentation and drawings are available on request.
